Hazardous Area Products

TALON offers sensors, transmitters, indicators, enclosures, and computers certified for use in hazardous area applications. TALON Technical Sales proudly represents high-quality hazardous area products from Intempco, PMC Engineering, Hoffer Flow Controls, Kahn Instruments, and Wilcoxon.

Hazardous area certified sensors are available for the following measurements:

TALON can also provide hazardous area certified signal conditioners, transmitters, barriers, displays, flow rate & totalizers, and HMI PC's.

Contact a TALON specialist about your applications and requirements, we will help you chose equipment meeting the necessary regulatory requirements for your project.




Touchscreen HMI Computer




Vulcan 24

Vulcan Hazardous Area Certified HMI from Strongarm Energy

Introducing the Vulcan series hazardous area certified Class 1 Div 2, Zone 2 HMIs: a versatile, feature-rich CSA, ATEX,and IECEx certified Panel PC.

  • Extended Operating Temperature -35 degrees Celsius to 60 degrees Celcius
  • Intel i7 Dual Core or Quad-Core processors
  • Feld swappable hard drives and components
  • Versatile, feature-rich US/CAN and ATEX/IECEx certified Panel PCs and displays



Contact Us

Temperature




Hazardous Area Products

Intempco Programmable Temperature Switch & Transmitter

  • CSA Class I Div. 1 Explosion Proof
  • Available 4-20 mA or voltage programmable signal output
  • Available fully programmable switch output; relay or transistor
  • Field re-programmable with optional PC interface module & software
  • Security password and tracking protection for re-programming and re-calibration
  • Utilizes self-calibration feature for accurate and stable performance
  • Utilizes Pt-100 Ohm RTD Class A element for temperature sensing
  • Standard SS316/SS316L construction
  • Type 4X, IP66/IP67 rated environmental protection
  • Easy installation with various mounting configurations



Contact Us


Pressure



Hazardous Area Products

The PMC ATM/F/IS Intrinsically Safe series has been designed for use in hazardous locations and is part of a comprehensive range of transmitters specifically designed for the process industry where fluids may clog, requiring a flush mount type of installation. Exceptional reliability is achieved with the high overpressure rating and the combination of high accuracy and long-term stability.



View The PMC ATM/F/IS Intrinsically Safe series


Hazardous Area Products

The PMC ATM/IS Intrinsically Safe series is specifically designed to meet the requirements of the process industry with various intrinsically safe approvals. The high performance/low cost combination offers the user a transmitter for use in many required applications.



View The PMC ATM/IS Intrinsically Safe series


Hazardous Area Products

The PMC ATM.1ST/IS is an electronically compensated pressure transmitter providing a 2-wire, 4-20 mA analog output. The transmitter offers accuracies of ≤ 0.05% FS or ≤ 0.1% FS including linearity, hysteresis, repeatability, zero and span setting errors. Further, the ATM.1ST/IS offers modular construction and the 20 year proven history of STS piezoresistive sensor technology.



View The PMC ATM.1ST/IS


Flow



Hazardous Area

This Hoffer Flow Controls I.S. Redi-Pulse Coil has been certified to CSA (with NRTL/C) and ATEX standards. The Redi-Pulse pickup coils are used with Hoffer turbine flowmeters and include a self-contained preamplifier within the pickup coil housing. The pickup coil produces a conditioned pulse output which offers the benefit of greater noise immunity when compared to standard pickup coils. The incorporation of the signal conditioning module into the pickup coil eliminates the need for conventional signal conditioners that are meter mounted in a junction box directly on top of the turbine flowmeter.



View The Hoffer Flow Controls I.S. Redi-Pulse Coil


Hazardous Area

The Hoffer Flow Controls HIT-2A in an Exd enclosure features a five digits of rate and eight digits of total, the HIT-2A is a DC, AC, loop or battery powered indicator capable of accepting magnetic pickup, DC pulse or switch closure inputs. The unit can be ordered with an optional loop powered 4-20mA output. The HIT-2A uses the 4- 20mA loop to provide power when this output is used.



View The Hoffer Flow Controls HIT-2A


Moisture



Hazardous Area

Kahn Easidew I.S. (Intrinsically Safe) Dewpoint Transmitter

  • Class I, Division 1, Groups A, B, C, D
  • Dewpoints from -148°F to +68°F
  • Accuracy to ±3.6°F
  • Pressures to 5000 PSIG
  • 4-20mA outputs
  • Temperature compensation



View The Kahn Easidew I.S. (Intrinsically Safe) Dewpoint Transmitter


Hazardous Area

Kahn Easidew PRO I.S. (Intrinsically Safe) Dewpoint Transmitter

  • FM/CSA certified for Class I, Division 1, Groups A, B, C, D
  • Heavy duty, process type NEMA 4 enclosure
  • Dewpoints from -148°F to +68°F
  • 4-20mA output configurable in °F, °C, or PPMv
  • 2-wire, loop-powered operation
  • Dewpoint accuracy of ±3.6°F
  • Pressures to 5000 PSIG



View The Kahn Easidew PRO I.S. (Intrinsically Safe) Dewpoint Transmitter


Hazardous Area

Kahn Easidew PRO I.S. (Intrinsically Safe) Hygrometer

  • FM/CSA certified for Class I, Division 1, Groups A, B, C, D hazardous environments
  • Heavy duty, process type NEMA 4 sensor housing
  • Dewpoints from -148°F to +68°F; ±3.6°F dewpoint accuracy
  • Dual alarm relays and scalable 4-20 mA or 0-10 VDC output
  • Includes digital display, I.S. dewpoint sensor, Galvanic Isolation Interface and sensor cable
  • Manual or auto pressure compensated PPMv, Lb/MMSCF or g/m3 measurement
  • Pressures to 5000 PSIG
  • Open sensor alarm



View The Kahn Easidew PRO I.S. (Intrinsically Safe) Hygrometer


Hazardous Area

Kahn Easidew PRO XP (Explosion Proof) Moisture Transmitter

  • CSA, ATEX, IECEx, certified for Class I, Division 1, Groups A, B, C, & D
  • Dewpoints from -166°F to +68°F (-110°C to +20°C)
  • 4-20 mA linear, configurable output signal
  • Rugged NEMA 4 weatherproof housing
  • 0-3000 PPMv moisture content in gas
  • 0-1000 PPMw moisture content in liquid
  • Explosion proof and flame proof
  • 2-wire, loop-powered operation
  • Dewpoint accuracy to ±1.8°F
  • 14 to 28 VDC operation
  • Pressures to 6500 PSIG
  • Dual conduit entry



View The Kahn Easidew PRO XP (Explosion Proof) Moisture Transmitter


Hazardous Area

Kahn HygroPort I.S. (Intrinsically Safe) Portable Hygrometer

  • FM/CSA certified for Class I, Division 1, Groups A, B, C, D hazardous environments
  • Dewpoint measurements from -148°F to +68°F; ±1.8°F typical dewpoint accuracy
  • Fast-responding internal ceramic sensor
  • Second process input channel for external transmitter
  • Internal data logging facility (log up to 320,000 points)
  • Bluetooth wireless interface to application software
  • 1/8" NPT inlet and outlet gas connections; stainless steel gas wetted parts
  • Pressure compensated PPMv, Lb/MMSCF or g/m3 measurements
  • 50 micron stainless steel sintered disk filter in the inlet port



View The Kahn HygroPort I.S. (Intrinsically Safe) Portable Hygrometer


Level



Hazardous Area

PMC Engineering Hazardous Environment Depth/Level Transmitter

  • Fully Submersible, 1" Diameter
  • Ranges: Scale (Zero based) 0-40" WC to 0-360 psig other ranges and pressure units can be specified
  • Accuracy: 0.1% & 0.25%
  • Material: 316L SS or Titanium
  • Output: 4-20 mA
  • FM/CSA Approved for Class 1, Div. 1



View The PMC Engineering Hazardous Environment Depth/Level Transmitter


Hazardous Area

Intempco Model LTX20 EX Fuel/Oil (Capacitance Transmitters/Level)

  • Designed for fuel, diesel, biofuel
  • 3/4" NPT Process Connection
  • 3/4” concentric tube design
  • Accuracy 1% of span for constant dielectric of material
  • Tube and inner probe SS316
  • For use with metallic and non-metallic tanks
  • OEM applications, low cost
  • Continuous loop powered 4-20mA operation
  • Non-interactive zero and span calibration
  • Explosion Proof USL/CNL
  • CSA Class 1 Div 2 Groups A,B,C,D



Contact Us


Hazardous Area

Intempco Model LTX20UL (Capacitance Level Transmitters)

  • Explosion Proof Design
  • Easy Calibration
  • Consistent Accuracy
  • Reliability
  • Housings
  • Mountings and Probes



Contact Us


Hazardous Area

Intempco Radar Level Sensors for Oil-Water Interface Detection

  • Explosion Proof For Class I, Div.1, Groups B, C, D
  • Self adjusting tracking radar ideal for oil-water interface detection
  • Programmable calibration
  • Output 4-20mA/20-4mA
  • Output sequences between interface level and oil level
  • Optional RS232, RS485 for communications with calibration, diagnostics & data logging software
  • PLC compatible (Modbus RTU)



Contact Us


Vibration



Hazardous Area

Intrinsically Safe & Explosion Proof Sensors: Wilcoxon has a wide range of certified accelerometers, vibration transmitters and transmitters to CSA and ATEX standards. Supportive accessories for the hazardous areas are also available.



Click to Request a Quote or call 281.999.8588
